Flexible Steel Conduits

ITCC Flexible Steel Conduit is manufactured with a continuous spiral wound strip of corrosion rust resistant and hot dipped galvanized steel

It suitable for concealed, exposed and approved raceways.

Our Flexible Steel Conduit is e wire temperature rated and has superior crush proof qualities, conforming to UL 1.

Applications:

  • Motor Feeder, Branch, Control circuit conductors
  • Environmental air-handling spaces
  • Concealed or exposed installations
  • Elevators, hoist ways escalators
Flexible,Silver,Metal,Conduits,Or,Metallic,Conduits,Pipe,For,Protect

Flexbile Metal Conduit - Steel (Weights And Dimensions)

Code Trade Size Internal Diameter
mm.
Outside Diameter mm. Min. Bending Radius(mm) Length of Conduit (M/Roll)
Min. Max. MIn. Max.
C-FC0050 1/2" 15.8 16.2 19.5 19.9 65 30
C-FC0075 3/4" 20.8 21.3 24.7 25.2 75 30
C-FC0100 1" 26.4 27.1 31.6/td> 32.1 100 15
C-FC-0125 1 1/4" 35.0 35.5 40.0 40.5 125 15
C-FC0150 1 1/2" 40.1 40.6 45.8 46.3 150 10
C-FC0200 2" 50.5 51.2 57.3 58.0 175 7.5

Liquid Tight Flexible Steel Conduits

ITCC Liquid Tight Flexible Steel Conduit is produced with galvanized steel strips and covered with heavy smooth PVC Cover Coating. It is UV Resistant and made to sustain temperatures between -20 Celsius and +55 Celsius. The PVC Coating provides a smooth surface onto which liquid tight compression fittings can be secured. They are produced as per UL 360.

Applications:

  • Indoor and outdoor installations where liquid tight proofing is required.
  •  Cable Management for conveyors, blowers, crane hoist, HVAC, machines and equipment.
  • Designed for both commercial and industrial projects.



LT Flexible Steel Conduit

Liquid Tight Flexbile Conduit - (Weights And Dimensions)

Code Trade Size Internal Diameter
mm.
Outside Diameter mm. Min. Bending Radius(mm) Length of Conduit (M/Roll)
Min. Max. Min. Max.
C-FLTC050 1/2" 15.80 16.31 20.83 21.34 85 30
C-FLTC075 3/4" 20.83 21.34 26.16 26.67 100 30
C-FLTC100 1" 26.44 27.08 32.77 33.40 120 30
C-FLTC125 1 1/4" 35.05 35.81 41.40 42.16 150 15
C-FLTC150 1 1/2" 40.00 40.64 47.37 48.26 180 15
C-FLTC200 2" 51.31 51.94 59.44 60.33 220 15

FMC Adaptors Data Sheets
